Belt Type Bucket Elevator is a common equipment for vertical conveying of bulk materials. Belt Type Bucket Elevator manufacturers differ in the specific design, manufacturing process and component selection of their products. These differences are reflected in the material and shape of the hopper, the type and width of the conveyor belt, the configuration of the drive device (such as motor power and reducer type), and the dust and sealing design of the overall structure. In addition, manufacturers with customization capabilities can produce equipment that meets specific needs.
What are the types of Belt Type Bucket Elevator?
Belt Type Bucket Elevator is a common equipment for vertical conveying of bulk materials. Its core component is the hopper, which can be mainly divided into two categories: stainless steel hopper and plastic hopper according to different materials. These two hoppers have their own characteristics and are suitable for different materials and working conditions.
Stainless steel hopper
Strong corrosion resistance: Stainless steel has excellent corrosion resistance and can effectively resist the erosion of chemicals such as acids, alkalis, and salts. It is especially suitable for industries with high requirements for hygiene and corrosion.
Good high temperature resistance: Stainless steel can maintain its mechanical properties and chemical stability at higher temperatures and is suitable for conveying high-temperature materials.
High strength and wear resistance: Stainless steel is strong and has good wear resistance. It is suitable for conveying materials with high specific gravity and strong abrasiveness.
Easy to clean: The surface is smooth, not easy to adhere to materials, and easy to clean.
Long service life: Due to its excellent corrosion resistance and wear resistance, stainless steel hoppers usually have a long service life.
Plastic hoppers
Light weight: Plastic hoppers are much lighter than stainless steel hoppers, which can effectively reduce the belt load and extend the service life of belts and bearings.
Good corrosion resistance: Most engineering plastics have good corrosion resistance to chemicals such as acids and alkalis, but the specific corrosion resistance depends on the type of plastic (such as polyethylene, nylon, polyurethane, etc.).
Good anti-sticking property: The surface of plastic is usually smooth and not easy to adhere to wet or sticky materials, reducing the frequency of material residue and clearing.
Reduce noise: The noise generated by plastic materials during operation is relatively low.
Low cost: Compared with stainless steel hoppers, plastic hoppers are usually cheaper to manufacture.
Wear-resistant and super-tough materials are available: Some high-performance plastics (such as polyurethane or super-tough nylon) have excellent wear and impact resistance and are suitable for abrasive materials.
Suitable for humid environments: Some plastic materials perform well in humid environments and are not easy to rust.
What are the advantages of Belt Type Bucket Elevator?
As an important vertical conveying equipment, Belt Type Bucket Elevator is widely used in many industries. Its advantages are mainly reflected in the following aspects:
High conveying efficiency: Belt Type Bucket Elevator can realize continuous and automatic conveying of materials, greatly improving the efficiency of the production process.
Save space: Unlike horizontal or inclined conveying equipment, bucket elevators mainly carry out vertical or large-angle conveying, which significantly reduces the required ground space, which is especially beneficial for companies with limited space or need to maximize the use of vertical space.
Reduce material loss and contamination: Bucket elevators usually use closed systems to minimize the risk of material exposure to the environment, thereby reducing material spillage and dust diffusion, reducing material loss, and helping to create a safer and cleaner working environment.
Low noise: Belt Type Bucket Elevator runs more smoothly and usually makes less noise than chain bucket elevator.
Wide range of applicable materials: Belt Type Bucket Elevator can handle many types of bulk materials, including granular, powdery and some irregular small pieces, and it can handle low temperature materials and free-flowing materials.
Flexible handling capacity: It can be customized according to the characteristics of the material (such as fragility) to achieve gentle or rough conveying. For example, continuous bucket elevator can achieve smooth loading and unloading of materials through a carefully designed bucket configuration and feeding system, avoiding "throwing" action and reducing material degradation.
What are the applications of Belt Type Bucket Elevator?
Belt Type Bucket Elevator is a mechanical equipment used for vertical conveying of bulk materials. Its core principle is to use a belt with a bucket to circulate around the head wheel and the bottom wheel to achieve material lifting. Belt Type Bucket Elevator has its wide application in the following aspects:
Vertical conveying of bulk materials: This is the main function of bucket elevator. It can lift various dry, granular or powdered bulk materials from low to high, such as conveying materials from the ground to silos, bins or subsequent processing equipment.
Connecting link in continuous conveying system: In many automated production lines and logistics systems, bucket elevators, as an important intermediate link, connect conveying equipment or processing units at different heights to ensure the continuity and smoothness of material flow.
Storage and discharging system: In large storage facilities (such as silos and material warehouses), bucket elevators are often used to lift materials to the storage port, or lift materials out from the bottom of the storage facility for the next step of processing or packaging.
Lifting light, fragile or abrasive materials: Since belts generate less noise and wear than chains when running at high speed, and the impact force on materials is relatively light, Belt Type Bucket Elevator is particularly suitable for lifting some materials that require a certain crushing rate, or abrasive materials that have high requirements for equipment wear.
Scenarios requiring higher conveying capacity: Belt Type Bucket Elevator can usually achieve higher conveying speeds and larger conveying capacities, so it is useful in places where a large amount of bulk materials needs to be handled, such as large warehouses, transfer stations, etc.
Belt Type Bucket Elevator is a mature material conveying equipment, and the products of different manufacturers show their own characteristics in details. These characteristics may involve the size of structural components, the focus of material selection, and the sophistication of assembly processes. For example, some manufacturers may provide a variety of hopper styles to accommodate materials of different particle sizes or viscosities, while others may enhance the wear resistance or high temperature resistance of the conveyor belt. The selection of equipment should be evaluated based on actual working conditions such as specific material properties, conveying capacity, lifting height, and on-site space.
