Automatic Multi-Lane Sachet Packaging Machine
Tuesday February-24 2026 16:36:36
Automatic Multi-Lane Sachet Packaging Machine can continuously package powders, granules, liquids, pastes, and other materials into individual sachets. The entire process is fully automated, requiring no manual operation and is faster than traditional single-lane packaging machines. It can process 300 to 1200 sachets per minute, with the exact speed varying depending on the number of rows and bag type. Commonly used models have 4 to 12 rows, while high-end models can expand to 24 rows. Single-bag weights range from 1 gram to 50 grams, and customized models can even produce 0.5-gram micro-packaging or 100-gram bulk packaging, suitable for various applications such as portable packaging and trial packs. The machine supports bag lengths from 40mm to 180mm and bag widths from 30mm to 120mm, and supports back-seal, three-side-seal, four-side-seal, and rounded-corner bags. Size adjustments are simple, and changing product specifications is convenient, increasing production capacity while producing neater and more aesthetically pleasing packaging.
How an Automatic Multi-Lane Sachet Packaging Machine Works
During operation, the automatic multi-lane sachet packaging machine feeds the roll of packaging film from the unwinding section. A photoelectric tracking system adjusts its position to align the pattern on the film with the sealing position. Multiple forming units simultaneously fold the film into individual small pouch shapes, and a longitudinal sealing component heats and seals the sides. Then, the metering system fills each row of pouches with the set amount of material. After filling, a transverse sealing component seals the pouch opening and prints the batch number, production date, and shelf life. Finally, a cutter separates the connected pouches, and the finished products are conveyed out by a conveyor belt. Defective pouches are automatically removed. All actions are controlled by a PLC, with bag making, filling, sealing, coding, cutting, and unloading completed step by step.
What are the functions of an automatic multi-lane sachet packaging machine?
An automatic multi-lane sachet packaging machine can complete various tasks in packaging production, meeting daily production needs. The equipment supports simultaneous operation of multiple rows and multiple channels, resulting in significantly faster packaging speeds compared to traditional single-unit machines, and consequently lower packaging costs per unit product. It is compatible with various metering methods such as screw, measuring cup, and piston, with a filling error controlled within ±1%, ensuring consistent weight in every bag. The equipment features a touchscreen interface, allowing for one-click setting of parameters, automatic parameter memorization, output statistics, and data storage. It also provides timely alarms in case of malfunctions, making operation very simple. Employing constant temperature heat sealing and independent tension control, it reduces the occurrence of incomplete or missing seals and can use various packaging materials such as composite films, aluminum foil films, and PE films. The machine body is primarily constructed of 304 stainless steel, facilitating cleaning, reducing production contamination, and meeting GMP requirements for food and pharmaceutical production. It is also equipped with safety doors and emergency stop devices for enhanced production stability.
Automatic Multi-Lane Sachet Packaging Machine Solutions
Automatic Multi-Lane Sachet Packaging Machines solve packaging challenges for various industries and can be configured flexibly and comprehensively to meet specific needs. In the food industry, powdered seasonings, instant drinks, and granular snacks can be packaged quickly. The machine is easy to clean and reduces contamination during production. In the pharmaceutical industry, it provides more stable metering, can be used in cleanroom environments, and can print traceability codes, complying with relevant standards for pharmaceutical production and management. Daily chemical products such as shampoos, conditioners, and skincare samples can also be packaged, preventing dripping and stringing during dispensing, resulting in a more aesthetically pleasing finished product. This equipment can also be used in conjunction with feeding, bagging, boxing, and cartoning equipment to form a complete automated production line, reducing manual intervention from raw materials to packaging.
The Automatic Multi-Lane Sachet Packaging Machine can perform multiple packaging operations simultaneously, adapting to different packaging capacities. It operates fully automatically from production to packaging and provides corresponding usage solutions for different industries. In the food, pharmaceutical, and daily chemical industries, it helps companies increase output, stabilize product quality, and rationally control production costs. This equipment simplifies the packaging process, reduces labor input, operates stably, and is suitable for various packaging scenarios. Small, portable products are increasingly popular in the market. This equipment can make packaging production smoother, reduce material waste, allow for more flexible adjustments, and enhance the company's competitiveness in the market.
