Manufacturers of liftable mobile belt conveyor have their own differences in technical paths, manufacturing processes and product characteristics. These differences are reflected in the equipment's overall dimensions, load-bearing capacity, operating stability, and adaptability to specific materials. Based on this difference, manufacturers can also provide highly customized production services to ensure that the equipment can accurately match the personalized needs of specific users. This includes the selection of conveyor belt materials, structural optimization of the frame, and the adaptation of drive methods.

What are the types of liftable mobile belt conveyor ?

Liftable mobile belt conveyor can be mainly divided into the following types according to the material and structure of their conveyor belts:

Strong wear resistance: Rubber belts have excellent wear resistance and are suitable for conveying various bulk materials such as ore, coal, sand and gravel, cement, etc.

Large bearing capacity: Rubber belts are usually thicker and have strong load-bearing capacity, suitable for conveying heavier or larger materials.

Good weather resistance: Strong adaptability to temperature changes and environment.

Better wear resistance: Better wear and cutting resistance than PVC belts.

Oil and fat resistance: It has stronger resistance to grease and fat, and is more suitable for the food processing industry.

Good elasticity: It has good flexibility and is not easy to deform.

Large angle conveying: The conveyor belt has corrugated sidewalls on both sides, and can be equipped with cross partitions, which can achieve large angles or even vertical conveying, saving space.

Prevent material scattering: The sidewalls effectively prevent materials from slipping or scattering during transportation, especially suitable for conveying bulk, granular, and powdered materials.

Diverse structures: The sidewall height and cross partition form can be customized according to the characteristics and inclination requirements of the conveyed materials.

How does the liftable mobile belt conveyor work?

The working principle of the liftable mobile belt conveyor can be decomposed into two parts: the conveying principle and the lifting and moving principle.

Conveying principle

The liftable mobile belt conveyor mainly relies on friction to drive the conveyor belt and materials:

Driving device: It is usually composed of a motor, a reducer and a transmission roller. The motor provides power, reduces the speed and increases the torque through the reducer, and finally drives the transmission roller to rotate.

Conveyor belt: The conveyor belt is the main body that carries the material. It wraps around the drive drum and the redirecting drum to form a closed loop.

Material conveying: When the drive drum rotates, the conveyor belt is driven to move by the friction between it and the conveyor belt. The material placed on the conveyor belt is then transported to the designated location.

Lifting and moving principle

Lifting mechanism: Common lifting mechanisms include screw lifting, hydraulic/pneumatic cylinders, and electric hoists/winch.

Wheeled base: The bottom of the conveyor is usually equipped with solid rubber wheels, pneumatic tires or track wheels, allowing it to move easily on the ground or on tracks.

Traction/self-propelled: Smaller mobile conveyors can usually be moved by manual or small vehicle traction. Large ones may be equipped with self-propelled drive devices (such as motor-driven wheels) to achieve autonomous movement and more convenient operation.

What are the advantages of liftable mobile belt conveyors?

Liftable mobile belt conveyors have significant advantages over fixed conveyors or other conveying equipment, making them the first choice in many application scenarios.

Flexibility and adaptability

Adjustable height: It can flexibly adjust the height and inclination of the conveyor according to the requirements of loading and unloading height, stacking height or different process flows.

Easy to move: Equipped with wheels, it can be easily moved between different work locations. This means that one device can serve multiple work points, greatly improving equipment utilization and reducing dependence on fixed infrastructure.

Strong site adaptability: It can work on relatively uneven ground without complex civil engineering, saving site construction costs and time.

Versatility

Wide range of applicable materials: Whether it is bulk materials (such as coal, sand, grain, fertilizer), or block materials, bagged materials, they can be transported by selecting the appropriate conveyor belt type (rubber belt, PVC/PU belt, sidewall belt).

Various operating modes: It can be used as an independent loading and unloading equipment, or it can be used in conjunction with other conveying equipment or production lines to form a more complex material handling system.

The key to choosing a suitable manufacturer of liftable mobile belt conveyors lies in the accurate grasp of current actual needs. Each manufacturer may have unique technical accumulation and production advantages in specific types of conveyor belt materials (such as rubber, PVC, PU), lifting mechanisms (such as screw type, hydraulic type) or frame structures. Therefore, during the selection process, users should fully communicate with the manufacturer to clarify their specific requirements for equipment length, width, conveying capacity, movement method, and material characteristics. In this way, customized products that better meet current operating conditions and functional requirements can be obtained.
