Micro-crushing machine price

Thursday September-11 2025  15:19:36

Micro-crushing machine price is not fixed. It depends mainly on the model, material, crushing capacity and customization. The price usually ranges from US$400 for a basic model to US$7,900 for an air flow crushing system. This large price difference directly reflects the core performance and output of the equipment. For example, the cost of a small crusher with a crushing capacity of 100 kg is significantly lower than that of a large crusher with a processing capacity of 2,000 kg per hour. This is because large equipment requires more durable materials, stronger motor drives, more complex manufacturing processes and more sophisticated control systems to ensure stable operation under high loads.

When choosing a crusher, Micro-crushing machine price is not the only consideration, it needs to be considered comprehensively in combination with your own needs. The material properties you need to crush (such as hardness and brittleness, moisture and viscosity, heat sensitivity, corrosiveness, and abrasiveness) directly determine the appropriate material (such as carbon steel or stainless steel) and the crushing fineness. Your desired processing capacity (tons/hour) is a key factor in selecting the machine size and power. Select a product based on these key parameters.

Micro-crushing machine price table

Model	Production capacity (kg/h)	Feed particle size (mm)	Discharge particle size (mesh)	Total power (kW)	Main speed (r/min)	Overall dimensions (mm)	Weight (kg)	Price
WFJ-15	10-100	≤10	80-450	13.5	6000	4200×1200×2700	950	$400 - $1,100
WFJ-20	60-150	≤10	80-450	17.5	4800	4700×1250×2900	1300	$800 - $2,100
WFJ-30	200-500	≤15	80-450	46	3800	6640×1300×3960	1500	$2,000 - $3,500
WFJ-60	300-800	≤20	80-450	84.15	2800	7500×2300×4530	3200	$2,500 - $4,500
WFJ-80	500-1000	≤20	80-450	102	2200	9800×2600×4550	3800	$3,100 - $5,900
WFJ-100	500-2000	≤30	80-450	122	1500	11000×2800×5000	4500	$4,000 - $7,900

What factors affect the price of Micro-crushing machine?

Micro-crushing machine price is mainly affected by different types and crushing amount, material cost, configuration and customization. Users can choose the model and related configuration based on the materials to be processed.

Equipment model and capacity

Micro-crushing machines can be divided into three types according to their materials and application scenarios: mechanical, airflow and laboratory. The prices of different types of Micro-crushing machines are also different.

Mechanical ultrafine pulverizer (such as WFJ series): price is about $1,000-$10,000, capacity is 10-5000kg/h, and the particle size of the output is 60-500 mesh, suitable for small and medium-sized food and medicinal materials processing to large-scale chemical and powder coating production needs

Airflow pulverizer (high-precision type): quoted price is $5,000-$69,000, the capacity is only 0.5-40kg/h, but the finished product fineness reaches D90＜3μm (adjustable 0.1-20μm), which is specially used for high value-added drugs (such as inhalers, anti-tumor drugs) and electronic materials.

Laboratory micro-volume machine: up to $18,000, supports 3g micro-sample cryogenic grinding, suitable for pharmaceutical research and development scenarios.

Material cost

Micro-crushing machine is made of 304 and 316L stainless steel, and the material is directly related to the durability and compliance of the equipment.

Food-grade 304 stainless steel: It is the mainstream of mid-range models (such as WFJ series), with moderate price, meeting the needs of food and general chemical industry;

Medical-grade 316L stainless steel: Surface finish ≤0.8μm Ra, no residue design. The price of models using this material is 30%-50% higher than that of 304 stainless steel models, and is used in sterile scenarios such as pharmaceuticals and biological laboratories.

Special configuration and customization

The additional functions of the Micro-crushing machine significantly increase the price. Common configurations include temperature control system, explosion-proof and inert gas protection, intelligent control system and bolt-free quick-release structure:.

Temperature control system: supports -30℃ freezing and crushing, solves the degradation problem of heat-sensitive materials (such as plant essential oils and proteins), and adds about $8,000-$2,000;

Explosion-proof and inert gas protection: used in flammable and explosive dust environments (such as metal powders and coatings), adds 15%-25%;

Intelligent control system: PLC automation control, touch screen operation interface (such as customized WFJ models), adds $1,000-$3,000;

Boltless quick-release structure: meets GMP standards, easy to clean and verify, with a premium of more than 20%.

Equipment customization

Micro-crushing If the standard machine model does not meet the user's needs, it needs to be customized, and the price will be $1000-$3000 higher.

Size and power customization: For example, non-standard enlarged grinding chamber or grading impeller, the price is 20%-40% higher than the standard model;

Industry deep customization: such as FD fruit and vegetable powder production line integration, inert gas circulation system for inhalants, the price can be doubled (+50%-100%)

How to choose a micro-crushing machine?

Choose the appropriate model according to Micro-crushing machine price. When choosing, consider the crushing fineness, crushing capacity, and material of the material to be crushed.

Regarding material selection, ordinary carbon steel (Q235) is the most economical choice. For processing corrosive materials or materials requiring food or pharmaceuticals, stainless steel (such as 304 or 316L) is recommended. It resists contamination, rusts, and is easy to clean. However, the price may be 1.5 times or even more than 2 times that of carbon steel equipment. Crushing capacity ranges from 100 kg to 2000 kg per hour, with a crushing fineness range of 10 to 450 mesh. It can crush high-hardness, high-purity, heat-sensitive, high-fiber, high-toughness, sticky, corrosive, or high-temperature materials. However, specialized design of the equipment material, sealing structure, and parameters is required, which increases manufacturing costs.

The price of Micro-crushing machine is uncertain. When choosing equipment, we need to conduct a comprehensive evaluation from multiple aspects such as crushed materials, output, application scenarios, etc., in order to choose the most cost-effective equipment.
