Fully automatic bagging packaging machine price
Saturday July-05 2025 14:54:23
Fully automatic bagging packaging machine price ranges from about $5,000 to $15,000, mainly affected by factors such as machine structure, applicable materials, degree of automation, and output. Entry-level models are suitable for simple granule or powder packaging, with prices ranging from $5,000 to $10,000; high-configuration equipment for liquids or those that require explosion-proof and anti-corrosion designs can cost up to $10,000 to $15,000.
Fully automatic bagging packaging machine is suitable for materials such as granules (such as rice, plastic particles), powders (such as flour, cement), and liquids (such as grease, sauces, chemical liquids, etc.). The equipment capacity is based on the material type and packaging bag capacity, usually 300-1200 bags per hour. The structure usually includes: feeding system, automatic weighing system, bag taking device, bag opening mechanism, filling system, sealing system, conveying system, and PLC control module.
What modules does the structure of a fully automatic bagging packaging machine include?
The core structure of the Fully automatic bagging packaging machine includes six modules: conveying system, bag positioning mechanism, filling unit, sealing device, intelligent control system, and safety protection system:
Conveying system: The empty bags are transported from the storage area to the filling station by belts or mechanical arms;
Bag positioning mechanism: Vacuum adsorption or mechanical grippers are used to achieve precise positioning, and the error is controlled within ±0.1mm;
Filling unit: Volumetric (such as screw feeding) or weighing (such as servo motor drive) technology is used to ensure the filling accuracy of ±0.5%;
Sealing device: Integrated heat sealing, ultrasonic or pulse sealing technology to support the sealing requirements of packaging bags of different materials;
Intelligent control system: The touch screen interface based on PLC can monitor production data in real time and supports multi-language operation;
Safety protection system: Equipped with emergency stop button, interlocking protective cover and dust collection device, it meets OSHA safety standards.
What are the advantages of the Fully automatic bagging packaging machine?
Fully automatic bagging packaging machine has the following advantages in structural design, price efficiency, scope of application, and industry:
Intelligent structure: Exclusive structural design for various materials ensures that the packaging process is fast, accurate, and clean, especially in liquid packaging, using food-grade stainless steel and anti-drip system.
Price advantage: low initial investment, saving labor, reducing losses, increasing speed, short payback period, suitable for large and medium-sized factories.
Material versatility: It can adapt to a variety of bag types and a variety of material states (granules, powders, liquids), and can quickly switch or replace molds as needed.
Widely applicable industries: widely used in grain, chemical, building materials, food, liquid seasoning, oil and fat, agricultural materials and other industries.
Fully automatic bagging packaging machine price
According to the material form classification, Fully automatic bagging packaging machine price is slightly different:
Granular packaging machines (such as rice, feed, resin granules) usually use gravity or belt feeding methods, which are suitable for materials with good fluidity. This type of equipment has a relatively simple structure, equipped with a bag sewing machine or heat sealing device for sealing, stable operation, convenient maintenance, and is widely used in grain, fertilizer and other industries. The price of this type of machine is generally between US$5,000 and US$8,000, which is suitable for small and medium-sized enterprises with certain requirements for packaging efficiency.
Powder packaging machines (such as flour, cement, and chemical powder) mostly use spiral conveying or negative pressure feeding systems, with dust removal and sealing structures to effectively prevent material dust and leakage. For flammable and explosive powders, explosion-proof design is also required. This type of equipment has a high degree of automation and high requirements for packaging accuracy and safety. The price is usually between US$8,000 and US$10,000, which is suitable for the refined production needs of food, building materials, and chemical industries.
Liquid packaging machines (such as edible oil, soy sauce, and liquid fertilizers) are equipped with quantitative filling systems such as flow meters, piston pumps, or gear pumps, and use food-grade stainless steel materials to ensure hygiene and safety. The equipment usually has a drip-proof filling head and a heat-sealing and aluminum foil sealing system to achieve accurate and clean liquid packaging. Due to its complex technology, high material requirements, and wide price range, generally between $10,000 and $15,000, it is often used in food, agriculture and chemical liquid filling production lines.
What materials are suitable for the Fully automatic bagging packaging machine?
The Fully automatic bagging packaging machine can be used for granular, powdered, liquid and other types of materials:
Granular: such as rice, corn, coffee beans, fertilizers, plastic granules, pet food, etc., with good fluidity, fast packaging speed and simplified structure.
Powder: such as flour, cement, milk powder, talcum powder, feed premix, etc., which are easy to dust, and the equipment needs to have sealing and dustproof functions.
Liquid: such as soybean oil, peanut oil, liquid condiments, chemical reagents, dairy liquids, etc., require accurate filling, anti-drip, anti-corrosion, and high requirements for equipment materials.
The Fully automatic bagging packaging machine is an indispensable equipment in the modern packaging industry. Whether it is granular, powdered or liquid materials, it can achieve fast, accurate and safe packaging needs through customized modules. Fully automatic bagging packaging machine price ranges from 5000 USD to 15000 USD, depending on configuration, materials, and capacity. Its diverse structural design and strong application range make it widely used in agriculture, food, chemicals, building materials, liquid filling and other fields. For enterprises pursuing capacity improvement and packaging automation, fully automatic bagging packaging machine is a cost-effective equipment worth investing in.
