Price of fully automatic ton bag packaging machine
Tuesday July-01 2025 15:58:24
Price of Fully automatic ton bag packaging machine is one of the most important factors that purchasing companies pay attention to when selecting a machine. This type of equipment is mainly used for automatic metering and packaging of bulk powder or granular materials from 500kg to 2000kg, and has the characteristics of high efficiency, high precision, and low labor dependence. Price of fully automatic ton bag packaging machine is usually between 8,000 and 30,000 US dollars, and the price range mainly depends on the equipment configuration, degree of automation, material adaptability and customer customization requirements. The basic equipment has relatively simple functions and is suitable for general materials; while the high-end model is equipped with an intelligent control system, dust prevention and dust removal device and automated auxiliary module, and the price will be higher.
What is the workflow of fully automatic ton bag packaging machine?
The operating process of fully automatic ton bag packaging machine is highly automated, including bagging, weighing, vibration compaction, sealing, and output. The specific steps are as follows:
(1) Bagging system: The rolled prefabricated ton bags are fed into the equipment through a conveyor belt, and the robotic arm or vacuum suction cup automatically opens the bag opening and accurately positions it below the filling port.
(2) Weighing and filling: High-precision sensors monitor material flow in real time, and ensure that the weight error is controlled within ±0.2%-0.5% through fast and slow dual-speed filling modes (such as filling a 1000kg ton bag at high speed to 950kg first, and then switching to low speed for fine-tuning).
(3) Vibration compaction: Some models are equipped with a vibration platform, which uses high-frequency vibration to evenly distribute the material in the bag to avoid the risk of damage caused by sedimentation during transportation.
(4) Sealing: According to the characteristics of the material, the bag mouth is sealed by hot melt sealing, sewing or ultrasonic welding to ensure moisture and leakage prevention.
(5) Finished product output: The sealed ton bag is transferred to the palletizing area or directly loaded onto the truck through a conveyor belt, realizing unmanned operation of the entire process.
Price range of fully automatic ton bag packaging machine
Price of fully automatic ton bag packaging machine is divided into basic, mid-range and high-end models. The specific price range is as follows:
(1) Basic model (US$7,000-21,000): Suitable for small-scale production or limited budget scenarios. This type of equipment focuses on cost control in design and has relatively simple functions. For example, manual bagging may be required in the packaging process, and the operation process is highly dependent on manual labor. Its weighing accuracy is about ±0.5%. Although it cannot meet high-precision requirements, it is fully adaptable to non-precision industries such as agriculture and building materials that do not require high precision.
(2) Mid-range model (US$22,000-66,000): Standard PLC control system, dust removal device and automatic bagging function. It can achieve more precise control and automated operation; the dust removal device effectively improves the working environment; the automatic bagging function greatly improves production efficiency. The weighing accuracy is improved to ±0.2% - 0.3%, and is widely used in standardized production scenarios such as fertilizers and feed.
(3) High-end model (US$66,000-220,000): It can be customized according to special needs. For example, chemical raw material production requires explosion-proof design to ensure safety, and the food industry uses nitrogen filling to extend the shelf life. High-end models can accurately meet these requirements and provide professional solutions for specific industries.
Price of fully automatic ton bag packaging machine price factors
The overall price of fully automatic ton bag packaging machine is affected by various factors such as automation, weighing accuracy, and processing capacity:
(1) Automation level: Models with automatic bag hanging, automatic detection, remote diagnosis and other functions are more expensive;
(2) Weighing system accuracy: High-precision weighing sensors and feedback systems will increase manufacturing costs;
(3) Feeding method and structural material: such as stainless steel anti-corrosion structure, high-temperature resistant structure, etc., are suitable for special industries but the price will also increase accordingly;
(4) Processing capacity: high-speed models can achieve a production capacity of 8-25 bags/hour, which is often used in high-capacity scenarios such as mineral powder and building materials;
(5) Customer customization: such as adding explosion-proof control, upgrading the brand of electrical parts, etc., will affect the final quotation.
Price of fully automatic ton bag packaging machine is a comprehensive reflection of equipment performance, configuration requirements and industry adaptability. Its price is affected by many factors, including material characteristics, production capacity requirements, workshop environment, budget range, equipment configuration, core component selection, degree of automation and customization requirements. Different materials have different requirements for sealing, weighing accuracy and dustproof performance, and the required configuration also changes accordingly. Overall, the price not only reflects the technical level and stability of the equipment, but also reflects its applicability in actual production and long-term operating costs. When purchasing, enterprises should combine their own needs and rationally evaluate the cost performance.
