What is a Vertical Vibrating Spiral Elevator Conveyor？
Vertical vibrating spiral elevator conveyors offer a compact solution for vertically transporting bulk materials while simultaneously performing thermal processing tasks. Dual counter-rotating vibration motors generate a consistent linear excitation force that propels materials upward along a continuous spiral track through a gentle micro-throwing motion. This design effectively minimizes particle abrasion and breakage, making the system particularly suitable for fragile granular and flake-shaped products across food, chemical, pharmaceutical, and mineral processing industries. The equipment is available with optional fully enclosed construction to eliminate dust emissions and meet food and pharmaceutical grade hygiene standards. Various configurations are offered, including open, fully sealed, and jacketed cooling designs, allowing integration with different production environments. Constructed from materials ranging from carbon steel to stainless steel grades, the unit accommodates specific sanitary or industrial requirements. With its vertical orientation, the conveyor substantially reduces floor space usage while enabling simultaneous material elevation and cooling, drying, or humidifying processes in a single pass.
What are the advantages of Vertical Vibrating Spiral Conveyor?
This vertical vibrating conveyor offers a compact, space-saving design that replaces long belt conveyors. It integrates elevating with simultaneous cooling, drying, or humidifying in one unit. The vibratory jumping motion handles materials gently, preventing abrasion or breakage of fragile granules and flakes. An optional fully enclosed construction ensures dust-tight operation and meets food/pharmaceutical hygiene standards.
Space-Saving Design：Vertical conveying structure with an ultra-small footprint, capable of replacing conventional long-distance belt conveyors.
Multi-Functional Integration：While vertically elevating materials, the vibration system simultaneously realizes material cooling, drying, or humidifying processes in one unit.
Gentle Material Handling：Materials travel upward via vibratory jumping motion, causing zero abrasion and no particle breakage for fragile granular and flake-shaped products.
Sanitary & Dust-Tight Construction：Fully enclosed design is available as an option to eliminate dust emissions, fully complying with food and pharmaceutical grade hygiene standards.
Working Principle of Vibrating Spiral Elevator
Our vertical spiral elevator utilizes two identical counter-rotating vibration motors installed symmetrically to produce a consistent linear excitation force. This vibrational force forces materials to perform a continuous upward micro-throwing movement along the spiral chute, achieving gentle and efficient vertical transportation.
Technical Parameters of Dahan Spiral Vibrating Elevator
| Model | Spiral Diameter (mm) | Max. Lifting Height (mm) | Capacity (t/h) |
|---|---|---|---|
| DZZ-500 | 500 | 3000 | 0.5 - 1.5 |
| DZZ-800 | 800 | 5000 | 1.5 - 3.5 |
| DZZ-1000 | 1000 | 6000 | 3.5 - 6.0 |
Note: Custom height and capacity are available upon request.
Wide Applications in Bulk Material Handling
This vertical vibrating conveyor is suitable for a wide range of industries and materials. In the food industry, it handles sugar, salt, coffee beans, milk powder, and nuts, with stainless steel 304/316L options for hygiene. In chemicals and plastics, it processes plastic pellets, rubber granules, resin, and fertilizer. For pharmaceutical and mining applications, it conveys powders, metal catalysts, sintered ores, and pellets, ensuring gentle handling and contamination-free operation.
Why should you choose us?
As a genuine manufacturer, we offer factory-direct pricing with no middleman markup. We provide full customization, including open, fully sealed, and jacketed cooling designs to suit various production needs. All equipment is CE and ISO9001 certified, ensuring reliable and stable quality.
Factory Direct Pricing:We are a genuine source manufacturer with no middlemen involved, allowing you to purchase equipment at factory-direct prices without extra markup.
Full Customization Support:Multiple structural designs are available to match your production demands, including open type, fully covered sealed type, and jacketed cooling style.
Authoritative Quality Certifications:All our machines are certified with CE and ISO9001 quality management system standards to guarantee stable and reliable equipment quality.
Frequently Asked Questions About Spiral Vibrating Elevators
Q1: Can a vibrating spiral elevator cool materials during lifting?
A1: Yes, by adding a cooling jacket, water-cooling deck, or forced air fans, it efficiently cools high-temperature materials while elevating.
Q2: What materials are suitable for this vertical conveyor?
A2: It is ideal for bulk solids, granules, pellets, and powders. However, it is not recommended for highly sticky or wet materials that adhere to the spiral surface.
Q3: How do I get a custom quote for my project?
A3: Simply contact our engineering team with your material type, bulk density, required capacity (t/h), and lifting height. We will design the optimal solution for you.
Vertical vibrating spiral elevator offers a space-saving, high-efficiency solution for gentle bulk material handling. It integrates vertical conveying with simultaneous cooling, drying, or humidifying in one compact unit, eliminating the need for long belt conveyors. The vibratory jumping motion prevents particle breakage, making it ideal for fragile foods, chemicals, pharmaceuticals, and minerals. With options for dust-tight, sanitary construction and stainless steel materials, it meets strict hygiene standards. As a direct manufacturer, we provide factory-direct pricing, full customization, and CE/ISO9001-certified quality. Contact us today with your specifications—we're ready to deliver the optimal solution for your operation.
